MPCD Agile Audio Video Mini Demodulator - Pico Digital

SKU:
MPCD
Condition:
New
Availability:
In Stock - Free Shipping!
Shipping:
Calculated at Checkout
MSRP: $249.99
$152.95
— You save $97.04

Description

The Pico Macom MPCD is a professional grade, frequency agile , microprocessor controlled CATV mini demodulator. The unit accepts any NTSC television signal in the 54-806MHz frequency-range converting it to baseband video and audio, while maintaining over 60dB S/N ratio. Up to 12 or 16 units can be installed “mix-and match” in Pico’s MPC-12, MPS-12, MPC-12R and MPC-16 chassis with MPCM45 and MPCMA mini-modulators. Its unique design enables it to be installed in other manufacturers’ mini-mod chassis. The unit’s phase-locked-loop frequency control, envelope signal detection, and superior SAW filtering minimize adjacent channel interference and assure accurate and spurious free performance. IRC or HRC offsets can be activated via push-button switches on the front panel. The unit’s PLL circuitry in conjunction with the non-volatile memory contained in the microprocessor ensures easy and reliable channel selection and restoration. The MPCD demodulator is shipped with all internal adjustments preset. Pico Macom backs up this product with its industry leading 5-year limited warranty.

Features:

  • 125 Channel frequency range 54~806MHz (CATV 2~13, A1~A5, A~ZZZ, 89~125, UHF 14~69)
  • Agile microprocessor control with push-button channel selection provides ease of installation, configuration and servicing
  • SAW filtered for precise adjacent channel rejection
  • >60dB Signal to noise ratio for crisp, sharp picture
  • Digital display provides quick channel identification
  • Non-volatile memory ensures channel programming remains after power loss
  • Single-slot design allows up to 12 or 16 units in Pico Macom's MPC-12, MPC-12R and MPC-16PS/CS chassis
  • Fully compatible with most other manufacturers' "mini-mod" chassis

Specifications:

Input Frequency Range 54~806MHz
Tuning Agile
RF Input Level 15dBmV
Noise Figure 5dB (VHF) / 7dB (UHF)
Video Detection Type Envelope
Video Frequency Response ±1.5dB
Video Signal to Noise 60dB
Audio Detection Type Quadrature FM
Audio Frequency Response 50~15,000Hz
RF Input Connection 75Ω F-Female
Video Output Connection 75Ω F-Female
Audio Output Connection 600Ω RCA-Female
Voltage Input +5, +12VDC
Dimensions 2.07” (L) x 8” (D) x 3.45” (H)
Weight 0.7 lbs.
View AllClose

Warranty Information

Pico Digital Warranties the Pico Maco MPCD Agile Audio Video Mini Demodulator for 5 Years.
