GHS-3PRO-M CATV MoCA Rated 3-Way Splitter - Holland Electronics

Holland Electronics GHS-3PRO-M MoCA Rated 3-Way Cable TV Splitter

Holland Electronics has developed a specialized line of CATV splitters for incorporating MoCA signal distribution and functionality throughout a home.

MoCA technology maximizes your home network by extending internet all over your house using your existing coax TV cable. Home network products with MoCA instantly turn your existing coax cable into a powerful, easy to access network for entertainment, Wi-Fi or just about anything you want.

Features:

• MoCA Rated 3-Way Splitter
• Low Isolation at MoCA Frequencies
• SCTE Compliant Flat-End F-Ports
• Enhanced Return Path Specifications
• Low Intermodulation Distortion
• Capacitor Decoupled
• 130 dB RFI Shielding
• 3-Way Ground Screw: Hex/Phillips/Slot

Specifications:

• Frequency: 5-1675 MHz
• Surge Withstand: 6kV
• 130 dB RFI Shielding
• Insertion Loss: 5-600 MHz: 3.8dB/7.5dB ; 600-1002 MHz: 4dB/7.8dB; 1125-1675 MHz: 6dB/11dB
• Isolation Port to Port: 25-32dB
• Input Return Loss: 20dB
• Output Return Loss: 20dB
