  • Holland MPOE-TM MoCA POE Filter for Cable TV Coaxial Networking

MPOE-TM Holland MoCA POE Filter for Cable TV Coaxial Networking - 50 Pack

$162.50
$349.50 (You save $187.00)
SKU: MPOE-TM-50
Availability:
In Stock - Ships Fast!
Condition:
New
Weight:
0.10 LBS
Free Shipping on $49 Order!
$3.99 on other US orders*
Qty

    Holland Electronics MPOE-TM MoCA P.O.E. Point of Entry Filter for Cable TV - Box of 50 Filters

    The Holland "POE" filter Model MPOE-TM was developed specifically for use on Cable TV subscriber premise internal coaxial network's wiring. The filters purpose is to BLOCK MoCA network generated data streams from exiting the subscriber's dwelling and interfering with other neighborhood MoCA networks. The Filter also improves MoCA network's throughput by improving the data paths micro reflections.

    Features:

    • Return Loss 20 dB Typical
    • Out-of-Band Rejection of up to 70dB Available
    • 6KV Surge Survivability
    • High-Performance Seizing Pin
    • Enviromentally sealed to prevent ingress of moisture and humidity
    • EMI Shielding > 130dB
    • Meets or Exceeds all SCTE Specifications
    • Compact Size
    • Approved for use in Time Warner Cable systems & other providers including TiVO utilizing MoCA for whole house DVR apps.
    • 50 Filters included

    Specifications:

    RF Pass Band:
    5-1002MHZ
    RF Stop Band:
    1125-1525MHz
    Band Rejection:
    1125-1525MHz
    >5dB
    Insertion Loss:

    PASSBAND
    5-42MHz
    42-550MHz
    550-1002MHz
    STOPBAND


    <1.5dB
    <0.1dB
    <0.4dB
    <1.5dB
    >35dB

    Return Loss:
    5-1002MHz
    15-550MHz
    550-1002MHz

    1125-1525MHz
    <14dB
    =22dB
    =17dB

    <1.5dB
    Surge Current Rating:
    IEEE 6KV A3 RING WAVE
    RFI:
    >100dB
    Group Delay:
    5-1002MHz (3.58MHz)
    <5 nSec
    OPS Tempurature:
    -40-140°F
    -40-60°C
    Pressure Integrity:
    <15 psi
    Weight:
    1.6 ounces
    45.4 grams
    Dimensions:
    .519 x 2.29 inches
    13.2 - 58.2mm
